Modern internal-combustion engines are controlled by logic, not luck. The Engine Control Unit (ECU) constantly reads dozens of sensors, runs control algorithms, and adjusts actuators to keep combustion efficient, responsive and clean. When you understand the feedback loops the ECU uses — and you can read the same signals with a proper scan tool — you stop chasing symptoms and start fixing causes.

This guide explains, with practical detail and testable workflows, how ECUs use sensor feedback to control combustion, what live data you should monitor, how to interpret patterns, and how to run targeted diagnostics with step-by-step checks.

Quick map — what you’ll learn

ECU role summarized.
Core sensors and what each contributes to combustion control.
Open-loop vs closed-loop control; STFT/LTFT explained with numbers.
Exact PIDs to monitor, expected ranges and red flags.
How to capture professional live-data logs (sample rates, labeling, overlays).
Practical diagnostic workflows for rough idle, lean under load, and intermittent misfires.
Two case studies with logs → diagnosis → fix.
Q&A and references.

1. The ECU in one practical sentence

The ECU is a real-time control system: it measures (sensors), decides (maps + algorithms), and acts (injectors, ignition, throttle, EGR), then repeats the loop hundreds of times per second to maintain target combustion conditions under changing load, temperature and driver demand.

2. Key sensors that form the combustion feedback loop (and why each matters)

I list the sensors you must know, with practical notes for diagnosis.

2.1 Mass Air Flow (MAF) — primary air mass measurement

What it says: grams/second entering the engine.
Why it matters: direct input to calculate injector pulse width; inaccurate MAF → wrong fueling.
Typical idle range (NA small-block V8): ~2–7 g/s; WOT numbers scale with displacement.
Red flags: sudden LTFT positive with low MAF readings → dirty/failed MAF or intake leak downstream of MAF.

2.2 Manifold Absolute Pressure (MAP) — pressure/engine load

What it says: manifold vacuum/pressure (kPa).
Use cases: speed/density engines, backup to MAF, boost control in turbo cars.
Diagnosis notes: fluctuating MAP with stable TPS often indicates valve or vacuum leak.

2.3 Oxygen (O₂) sensors / AFR sensors — combustion result

What they say: residual O₂ or AFR post-combustion (voltage or wideband AFR).
Why critical: closed-loop corrections rely on upstream O₂ switching or wideband values.
Red flags: slow switching, stuck readings, or opposite bank behaviour → sensor or exhaust leak.

2.4 Short-term & Long-term Fuel Trim (STFT / LTFT) — ECU adaptation

What they say: % corrections ECU adds/subtracts per bank.
Interpretation: STFT = immediate corrective action; LTFT = learned compensation.
Healthy band: ±10% typical; sustained >±20% = significant issue.

2.5 Coolant Temp (ECT) & Intake Air Temp (IAT) — density and enrichment logic

Function: cold enrichment, warm-up calibration, fuel/map selection.
Red flags: cold temp reading when engine is warm → rich conditions, poor economy.

2.6 Throttle Position (TPS) / Accelerator Pedal Position (APP) — driver demand

Use: determines transient fueling, torque requests, shift logic in automatics.
Red flag: TPS that lags APP indicates sensor or electronic throttle mismatch.

2.7 Crank (CKP) & Cam (CMP) sensors — synchronization

Function: timing reference for injection and ignition; necessary for sequential injection.
Failures cause: misfires, no-start, inaccurate timing advance.

2.8 Fuel rail pressure & pump status — fuel supply health

Why watch: low dynamic pressure under load = fuel supply problem (pump/regulator/filter).
Pattern: good at idle, collapses at WOT → pump or supply restriction.

3. Open-loop vs closed-loop — the heart of feedback control

Open-loop: ECU follows map tables (cold start, WOT, limp mode). No O₂ feedback.
Closed-loop: ECU uses O₂ or AFR feedback to adjust injector duration via STFT. Most daily driving is closed-loop once warm.

Practical rule: if O₂ sensor is disabled/bad or ECT is cold, readings are open-loop — fuel trims don’t reflect real combustion. Always confirm mode before interpreting STFT.

4. Fuel trims — how to read them like a pro

STFT example: +12% (ECU currently adding 12% fuel)
LTFT example: +8% (longer-term learned +8%)
Total compensation: STFT + LTFT ≈ +20% → ECU is compensating heavily for a lean condition. That should move you to inspect MAF, vacuum, fuel pressure.

Diagnostic pairing: Always pair trims with MAF / MAP and fuel pressure. Trims alone are ambiguous.

5. Essential PIDs to monitor (build a “quick-check” screen)

Create a reusable live-data screen in your scanner including:

Engine RPM
Vehicle Speed
MAF (g/s) or MAP (kPa)
TPS / APP (%)
STFT / LTFT (bank 1 & 2)
O₂ voltages or wideband AFR (pre-cat sensor)
Injector pulse width (ms) or duty % per cylinder
Fuel rail pressure (psi/kPa)
Engine coolant temp (°C/°F)
Intake air temp (°C/°F)
Misfire counters (per cylinder)
Battery voltage (key on / cranking / running)

Why: that set covers >85% diagnosable drivability issues.

6. Professional live-data capture: sample rates, labeling, overlays

Sample rates

Idle/static trends: 5–10 Hz (samples/sec)
Transients, shifts, misfires: 20–50 Hz
Injector/solenoid PWM: >200 Hz or use an oscilloscope

Labeling

Always annotate log start time and test phase (e.g., cold idle, 25% throttle step, 50–75 mph cruise).
Use event markers for manual actions (e.g., “A/C on”, “foot off throttle”).

Overlays

Plot MAF vs STFT, or Commanded Line Pressure vs Actual. Overlaying shows cause–effect.

Storage & export

Export CSV for offline analysis. Keep baseline logs of a known-good vehicle of same model for comparison.

7. Diagnostic workflows — step-by-step (practical)

Below are workflows tuned for technicians. Follow them in order — don’t skip.

Workflow A: Rough idle / intermittent misfire (cold-start & warm)

Read stored DTCs + freeze frame. Note misfire counters.
Capture cold-start log: RPM, ECT, MAF, STFT/LTFT, injector PW, O₂s. Sample 10–20 Hz.
If STFT/LTFT strongly positive on one bank → suspect intake leak / MAF / injector.
Use cylinder disable (one-by-one) or balance test to isolate cylinder. If disabling a cylinder does not change RPM significantly → that cylinder was not contributing (possible injector/valve/compression).
If misfire follows coil/injector when swapped → swap confirmed.

Workflow B: Hesitation or lean under load (acceleration complaint)

Capture dynamic log during acceleration: MAF, fuel pressure, STFT, TPS, commanded torque.
Observe fuel pressure under load. If pressure collapses while duty cycles saturate → fuel supply.
If MAF flat vs RPM rise → MAF or harness issue.
Cross-check O₂ response timing.

Workflow C: Transmission or torque-related hesitation (VLP focus)

Log Desired vs Actual Line Pressure, Solenoid Duty, Input/Output speeds and TCC slip at 20–50 Hz during shift events.
Commanded high pressure but actual low + solenoid duty at maximum = hydraulic fault (pump/valve body leak).
Excessive slip with correct pressures → clutch pack wear.

8. Two concise case studies (realistic logs → diagnosis → fix)

Case 1 — “Cold-start rough idle that clears when warm”

Symptoms: rough idle for first 3–4 minutes, then smooth. No codes.

Live data (cold): ECT showing 25°C although engine temp rising; STFT +18% → LTFT +12% → MAF low for RPM. O₂ sensors switching slowly.

Interpretation: incorrect coolant temp reading (ECT stuck low) → ECU in cold enrichment / open-loop longer than needed → overfueling correction swings. MAF low may be a secondary effect.

Fix: Replace ECT; verify MAF and trims after warm-up. Result: STFT <±3% and normal idle.

Case 2 — “Power loss under load only”

Symptoms: normal idle; under heavy throttle car stumbles.

Live data (accel): fuel rail pressure 30% below spec during WOT; fuel pump voltage at pump dropping 1.5V under load; STFT spikes positive.

Interpretation: pump supply voltage drop causes insufficient flow → pressure collapse under demand → lean condition under load.

Fix: Check wiring/connector at pump; replace pump due to failing motor. Post replacement: pressure stable, trims normalized.

9. Advanced notes — Mode 06, Freeze Frame, and CAM/CRANK correlations

Mode 06: numeric component test results. Use when bench-testing sensors and to validate thresholds.
Freeze Frame: critical to capture the exact pre-DTC state. Don’t clear before logging.
CAM/CRANK correlation: misaligned signals show up as erratic timing or multiple random misfires — essential when diagnosing cam timing or failed timing chains.

10. Tools & hardware (what pros use and why)

Handheld scanner with 20–50Hz sampling and CSV export — indispensable for real driving logs.
PC-based logging software (for large overlays and advanced plotting).
Oscilloscope — for injector/coil waveform verification and PWM solenoid analysis.
Fuel pressure gauge & mechanical vacuum gauge — verify sensor claims.
Digital storage & templates — maintain baseline logs per model.

If you plan to build a shop library: keep model-year baseline logs and test reports.

Q&A — the essentials (short, authoritative)

Q1 — What sample rate is enough for live-data logging?
Use 5–10 Hz for slow trends, 20–50 Hz for transients (shifts, misfires). For injector/solenoid PWM, use an oscilloscope.

Q2 — STFT shows +20% but MAF looks normal — what next?
Check for intake leaks and fuel pressure under load. Also validate MAF readings with a mechanical flow test or swap to known-good MAF.

Q3 — Can I trust O₂ voltage alone?
No. O₂ voltage must be interpreted with STFT/LTFT, MAF and fueling. A stuck high/low voltage could be sensor or real mixture fault.

Q4 — Is it OK to clear codes before testing?
No. Log first. Clearing removes freeze frame and hampers root-cause correlation.

Q5 — Which is more important: fuel pressure or injector pulse width?
Both. Pulse width shows command; pressure + flow show delivery. A correct pulse width with low pressure produces lean real fuel mass — so interpret together.

References & further reading (authoritative starting points)

SAE papers on closed-loop fuel control and transient fueling.
Bosch Automotive Handbook (sensor & ECU fundamentals).
OEM service manuals for model-specific live data PIDs and expected values.
Practical shop guides on fuel trim interpretation and fuel pressure testing.

(Note: use OEM tables for exact PID expected ranges for each vehicle — ranges in this article are indicative and used for teaching pattern recognition.)

Short disclaimer:

This article is for educational purposes. Always follow OEM service procedures and safety practices. When in doubt, consult factory documentation or a certified technician.
